Send InquiryDrilling Cum Milling Machine
Product Details:
- Product Type Cum Milling Machine
- Material Mild Steel
- Computerized No
- Automatic Grade Semi-Automatic
- CNC Or Not Normal
- Voltage 220 - 380 Volt (v)
- Weight (kg) 970 Kilograms (kg)
85000 INR/Number
X
Drilling Cum Milling Machine Price And Quantity
- 85000 INR/Number
- 1 Number
- 85000.00 - 90000.00 INR/Number
Drilling Cum Milling Machine Product Specifications
- Semi-Automatic
- 220 - 380 Volt (v)
- Green
- No
- Mild Steel
- Cum Milling Machine
- Normal
- 970 Kilograms (kg)
Drilling Cum Milling Machine Trade Information
- Cash in Advance (CID) Cash Advance (CA)
- 1 Number Unit Per Day
- 1 Days
- Gunny Bag
- All India
Product Description
SI-3M (40mm Cap. Drilling Cum Milling Machine)
The Company:
SIDDHAPURA ENGINEERING WORKS, it's a venture of SIDDHAPURA GROUP, It's has come in to existence for last 34 years. With a vast experience of 34 years in the field of machine tools engineering and manufacture of Pillar and Radial drilling machines. It's main assents is rigid quality inspection methods combined with skilled workmanship led by a team of technically qualified and experienced personnel and dedicated personal attention.
SIDDHAPURA ENGINEERING WORKS aims at creation of wide industry platform in manufacture of drilling machine in wide ranges in mutual benefit between supplier and buyers besides maintaining services, help and close links.
Some important features:
- Proportioned column for rigidity of machine
- Rough and smooth feed available by manual and power feed.
- Provision of window for change of gear on top cover.
- Quill spacer made of mild steel
- Main spindle made of EN steel with 6 slots. 8 speed in either direction.
- Grounded parts finished on imported grinding machine.
- Major parts castings are of standard grade.
- Head stock is bored on imported boring machine
- Spindle sleeve is properly guided in honed drill head bore on 6 ball and roller bearings for smooth and accurate running.
Model No. SI-3M
| Drilling | 40 mm |
| Face Mill | 100 mm |
| End Mill | 25 mm |
| Tapping | 22 mm |
| In mild Steel Drilling | 35 mm |
| Column Diameter | 130 mm |
| Swing | 610 mm |
| Working Surface | 435 x 200 mm |
| Longitudinal Travel Manual | 325 mm |
| Cross Travel | 250 mm |
| Vertical Travel | 400 mm |
| Quill Travel | 220 mm |
| Spindle Taper | MT-4 |
| Range of Spindle Speed | 75 to 2070 RPM |
| No. of Spindle Speed | 8 |
| Distance Spindle To base | 940 mm |
| Base Size (Machine Area) | 490 x 470 mm |
| Overall Height with Guard | 1830 mm |
| Main Electrical Motor | 1.5 HP |
| V-Belt Section | B-62 |
| Shipping Case (L x W x H) | 1140 x 800 x 1950 mm |
- Standard Accessories: Motor Pulley, Drift Key, Milling Collect Adapters.
- Optional Accessories: Coolant Pump, Electrical Motor and R and F Switch, Square working table.
